1P NO 10A push button bell symb.2M white - 14008.2.C

Pdf
Vimar - 14008.2.C - 1P NO 10A push button bell symb.2M white
Vimar - 14008.2.C - 1P NO 10A push button bell symb.2M white

14008.2.C
Wiring devices / Traditional wiring devices / PLANA / Devices

1P NO 10A push button bell symb.2M white
1P NO 10 A 250 V~ push button, bell symbol, lightable, replaceable button, white - 2 modules

产品状态
3 - Active

图纸

PNG DXF
PNG DXF
PNG DXF
Class group
Domestic switching devices
Class
Push button
Assembly arrangement
Modular device for domestic switching devices
Model
Single push button
Method of operation
Push button
Number of rockers
1
Number of modules (module system)
200
Number of poles
1
Nominal voltage
250 V
Rated current
10,00 A
With lighting
Yes
Feedback-signal contact
No
Mounting method
Flush-mounted
Type of fastening
Engage (snap)
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Untreated
Surface finishing
Glossy
Colour
White
RAL-number (similar)
9003
Transparent
No
Label space/information surface
Yes
Suitable for degree of protection (IP)
IP40
Device width
44,80 mm
Device height
49,00 mm
Device depth
38,40 mm

00. CE Marking - EU

01. IMQ - Italy

10. EAC Eurasian Customs Union

13. SNI - Indonesia

14. TSE - Turkey

15. CCC - China

19. NOM - Mexico

28. NSW - Australia

29. QCERT - Colombia

31. TISI - Thailand

37. Marking - Morocco

43. UKCA mark - Great Britain

96. Electrotechnical expert

99. WEEE Directive

最小订单数量: 20 NR

条形码

Barcode Qty 1 NR
8007352119994
1 NR
5.1x4.3x5.3 [cm]
37.07 [g]
Barcode Qty 20 NR
8007352120006
20 NR
26.9x11.6x9 [cm]
779 [g]
Barcode Qty 240 NR
8007352640672
240 NR
38x28.5x35.5 [cm]
10,140 [g]
问题： What is the minimum and maximum operating temperature?
回答： The specifications regarding the room operating temperatures valid for our electromechanical controls are as follows: - They must not exceed 40°C, considering also that an average of 35°C must not be exceeded in a 24-hour period. - They must not drop below -5°C.
