Antibacterial 1P 16AX reversing switch - 14013.AB

Pdf

14013.AB
Wiring devices / Traditional wiring devices / PLANA / Devices

Antibacterial 1P 16AX reversing switch
1P 16 AX 250 V~ reversing switch, lightable, replaceable button, with antibacterial treatment, white. Max 200 W for self-ballasted lamps (IEC 60669-1:2017)

产品状态
3 - Active

图纸

Class group
Domestic switching devices
Class
Installation switch
Wiring system
Intermediate switch
Method of operation
Rocker/button
Assembly arrangement
Modular device for domestic switching devices
Number of modules (module system)
1
Push button switch
Yes
Number of rockers
1
Mounting method
Flush-mounted
Type of fastening
Engage (snap)
With mounting plate
No
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Untreated
Surface finishing
Glossy
Colour
White
RAL-number (similar)
9003
Label space/information surface
Yes
Illumination
Optional
Function lighting
Control and orientation
Type of lighting
LED exchangeable
Suitable for degree of protection (IP)
IP40
Nominal voltage
250 V
Rated current
16,00 A
Feedback-signal contact
No
Connection type
Screwed terminal
Washing machine switch
No
Device width
22,30 mm
Device height
49,00 mm
Device depth
38,70 mm
Built-in depth
24,00 mm

00. CE Marking - EU

10. EAC Eurasian Customs Union

20. IQC - Argentina

31. TISI - Thailand

37. Marking - Morocco

43. UKCA mark - Great Britain

最小订单数量: 50 NR

条形码

Barcode Qty 1 NR
8007352499393
1 NR
4.1x2.8x5.3 [cm]
36.1 [g]
Barcode Qty 50 NR
8007352499409
50 NR
21.6x11.6x14.3 [cm]
1,909 [g]
