2P 45A 1-way switch COOKER 3M Silver - 14018.CK.SL

Pdf
14018.CK.SL

Plana Silver / Devices / Basic devices

2P 45A 1-way switch COOKER 3M Silver
2P 45 A 250 V~ 1-way switch, lightable, COOKER symbol, with built-in frame for British standard boxes, to complete with 3-module British standard cover plates, Silver. Max 200 W for integrated ballast lamps (IEC 60669-1:2017)

产品状态
3 - Active

Class group
Domestic switching devices
Class
Switch
Wiring system
2-pole switch
Method of operation
Rocker/button
Assembly arrangement
Other
Number of modules (module system)
3
Push button switch
Yes
Number of rockers
1
Mounting method
Flush mounted (plaster)
Type of fastening
Screw mounting
With mounting plate
No
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Lacquered
Surface finishing
Glossy
Colour
Silver
RAL-number (akin)
9006
Label space/information surface
Yes
Illumination
Optional
Function lighting
Control and orientation
Type of lighting
Not included
Suitable for degree of protection (IP)
IP40
Nominal voltage
250 v
Rated current
45 A
Feedback-signal contact
No
Connection type
Screwed terminal
Washing machine switch
Yes
Width of device
82,50 mm
Height of device
82,50 mm
Depth of device
32,50 mm
Built-in depth
22,50 mm
最小订单数量: 10 NR

条形码

Barcode Qty 1 NR
8007352406421
1 NR
8.5x3.9x8.6 [cm]
115.9 [g]
Barcode Qty 10 NR
8007352406438
10 NR
20.7x18.5x9.6 [cm]
1,254 [g]
