2P 16AX 1-way switch +000-key white - 14083.CU

Pdf
Vimar - 14083.CU - 2P 16AX 1-way switch +000-key white
Vimar - 14083.CU - 2P 16AX 1-way switch +000-key white

14083.CU
Wiring devices / Traditional wiring devices / PLANA / Devices

2P 16AX 1-way switch +000-key white
2P 16 AX 250 V~ key-operated 1-way switch, with 000 unified key, white. Max 200 W for self-ballasted lamps (IEC 60669-1:2017)

产品状态
3 - Active

图纸

PNG DXF
PNG DXF
PNG DXF
Class group
Domestic switching devices
Class
Installation switch
Wiring system
2-pole switch
Method of operation
Key
Assembly arrangement
Modular device for domestic switching devices
Number of modules (module system)
1
Push button switch
Yes
Number of rockers
0
Mounting method
Flush-mounted
Type of fastening
Engage (snap)
With mounting plate
No
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Untreated
Surface finishing
Glossy
Colour
White
RAL-number (similar)
9003
Label space/information surface
Yes
Illumination
No
Function lighting
Other
Type of lighting
Other
Suitable for degree of protection (IP)
IP40
Nominal voltage
250 V
Rated current
16,00 A
Feedback-signal contact
No
Connection type
Screwed terminal
Washing machine switch
Yes
Device width
22,30 mm
Device height
49,00 mm
Device depth
41,40 mm
Built-in depth
30,50 mm

00. CE Marking - EU

10. EAC Eurasian Customs Union

14. TSE - Turkey

20. IQC - Argentina

28. NSW - Australia

29. QCERT - Colombia

37. Marking - Morocco

43. UKCA mark - Great Britain

96. Electrotechnical expert

99. WEEE Directive

最小订单数量: 20 NR

条形码

Barcode Qty 1 NR
8007352108707
1 NR
5.1x2.8x5.3 [cm]
51 [g]
Barcode Qty 20 NR
8007352108714
20 NR
27x11.6x6 [cm]
1,090 [g]
Barcode Qty 120 NR
8007352651142
120 NR
37.5x30x13.5 [cm]
6,900 [g]
