Vimar - 14148 - MASTER dimmer 120-230V white

14148
Wiring devices / Traditional wiring devices / PLANA / Devices

MASTER dimmer 120-230V white
Dimmer, 120-230 V~ 50-60 Hz, for: 40-500/40-800 W incandescent lamp, 40-300/40-500 VA ferromagnetic transformers, control and regulation with built-in push button or from peripheral NO push buttons, MASTER function, TRIAC technology, visible in darkness, white

产品状态
2 - Will be discontinued

单, 说明书, 文档

Multilanguage instructions sheet (270 kb)

图纸

PNG DXF

PNG DXF

PNG DXF

Class group
Domestic switching devices

Class
Dimmer

Method of operation
Push button

Type of load
Inductive load

Applicable with button
Yes

Applicable with movement sensor
No

Applicable with presence indicator
No

Applicable with time switch/timer
No

Applicable with transmission button
No

Applicable with infrared button
No

Mounting method
Flush-mounted

Type of fastening
Snapper mounting

Material
Plastic

Material quality
Thermoplastic

Surface protection
Untreated

Surface finishing
Glossy

Colour
White

RAL-number (similar)
9003

Transparent
No

Suitable for degree of protection (IP)
IP40

Nominal voltage
120,00 - 230,00 V

Frequency
50,00 - 60,00 HZ

Control voltage
120,00 - 230,00 V

Device width
22,30 mm

Device height
49,00 mm

Device depth
54,80 mm

00. CE Marking - EU

43. UKCA mark - Great Britain

99. WEEE Directive

最小订单数量: 10 NR

条形码

8007352326545

1 NR

5.1x4.3x5.3 [cm]

53.87 [g]

8007352326552

10 NR

26.9x11.6x4.9 [cm]

603 [g]
