14196.SL
Wiring devices / Traditional wiring devices / PLANA / Devices
Quid - Rolling shutters 2-way switch Sil
Quid electronic switch for centralised operation of roller shutter with slat orientation with relay outputs for cosφ 0.6 motor 2 A 220-240 V~ 50/60 Hz, position saving, Silver
产品状态
2 - Will be discontinued
您可能也感兴趣
图纸
Class group
Domestic switching devices
Domestic switching devices
Class
Push button
Push button
Assembly arrangement
Modular device for domestic switching devices
Modular device for domestic switching devices
Model
Group push button
Group push button
Operating method
Push button
Push button
Number of rockers
1
1
Number of modules (module system)
100
100
Number of poles
2
2
Rated current
5,00 A
5,00 A
With lighting
Yes
Yes
Monitoring contact
No
No
Mounting method
Built-in
Built-in
Type of fastening
Engage (snap)
Engage (snap)
Material
Plastic
Plastic
Material quality
Thermoplastic
Thermoplastic
Surface protection
Lacquered
Lacquered
Surface finishing
Glossy
Glossy
Colour
Silver
Silver
RAL-number (similar)
9006
9006
Transparent
No
No
Label space/information surface
Yes
Yes
Device width
22,30 mm
22,30 mm
Device height
49,00 mm
49,00 mm
Device depth
51,10 mm
51,10 mm
最小订单数量: 10 NR
条形码
8007352623057
1 NR
5.1x4.3x5.3 [cm]
45.2 [g]
8007352623064
10 NR
26.9x11.6x4.9 [cm]
473 [g]
8007352623699
200 NR
47.5x27x29 [cm]
9,580 [g]
