2P+E 16A P30 outlet +C16 CB white - 14276

Pdf
14276

Plana / Devices / Protected socket outlets

2P+E 16A P30 outlet +C16 CB white
2P+E 16 A 250 V~ SICURY socket outlet, Italian standard P30 (lateral and central earth contacts), interlocked with 1P+N C 16 circuit breaker, supply voltage 230 V~ 50 Hz, breaking capacity 3000 A, white - 3 modules

产品状态
3 - Active

Class group
Domestic switching devices
Class
Socket outlet
Model
Italian type P30
With built-in USB power supply
No
Number of units
2
Number of modules (module system)
3
Number of socket outlets switchable
1
Imprint/indication
None
Connection type
Screwed terminal
With hinged lid
No
With enhanced contact protection
Yes
Label space/information surface
Yes
Colour
White
RAL-number (similar)
9003
Metallic colour
No
Transparent
No
Lockable
No
Eject-mechanism
No
Insulated mounting
No
With function lighting
No
With orientation lighting
No
Over voltage protection
No
Fault current protection
No
With miniature fuse
No
Mounting method
Flush mounted (plaster)
Type of fastening
Snap mounting (engagement)
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Untreated
Surface finishing
Glossy
With on/off switch
Yes
With loop through function
No
Rotated central insert
No
Nominal current
16 A
Nominal voltage
230 v
Frequency
50,00 - 60,00 HZ
Suitable for degree of protection (IP)
IP20
Impact strength
Other
Width of device
67,30 mm
Height of device
49,00 mm
Depth of device
56,30 mm

00. CE Marking - EU

10. EAC Eurasian Customs Union

37. Marking - Morocco

最小订单数量: 5 NR

条形码

Barcode Qty 1 NR
8007352112834
1 NR
5.2x5.7x7.6 [cm]
119.1 [g]
Barcode Qty 5 NR
8007352112841
5 NR
21.4x11.6x6 [cm]
652.9 [g]
