Step marker lamp 230V

Pdf

14390
Wiring devices / Traditional wiring devices / PLANA / Devices

Step marker lamp 230V
Step marker lamp, 230 V~ 3 W max, with adjustable beam, for 14770, 14771, 14776 and 14777 lamps, white diffuser, white - 2 modules. Provided without lamp

产品状态
2 - Will be discontinued

图纸

PNG DXF

Class group
Domestic switching devices

Class
Information light signal for domestic switching devices

Number of modules (module system)
2

With light source
No

Lamp type
Incandescent lamp

With flashlight
No

With fixed symbol/imprint
No

With exchangeable symbol
No

Mounting method
Flush-mounted

Type of fastening
Engage (snap)

Material
Plastic

Material quality
Thermoplastic

Surface protection
Untreated

Surface finishing
Glossy

Colour
White

RAL-number (similar)
9003

Transparent
No

Colour light source
White

Suitable for degree of protection (IP)
IP40

Nominal voltage
230 V

Max. lamp power
3 W

00. CE Marking - EU

37. Marking - Morocco

43. UKCA mark - Great Britain

96. Electrotechnical expert

99. WEEE Directive

最小订单数量: 10 NR

条形码

8007352117662

1 NR

6x5.4x5.3 [cm]

41.7 [g]

8007352117679

10 NR

28.1x13.1x6 [cm]

502 [g]

8007352644939

120 NR

38.5x29x30 [cm]

6,504 [g]
