Emergency lighting device 230V - 14394

Pdf
Vimar - 14394 - Emergency lighting device 230V
Foto gallery #1
Foto gallery #2
Vimar - 14394 - Emergency lighting device 230V

14394
Wiring devices / Traditional wiring devices / PLANA / Devices

Emergency lighting device 230V
Emergency lighting fitting, 230 V~ 50-60 Hz, Ni-Cd rechargeable battery, FD 4W G5 fluorescent lamp and mounting frame for 6/7-module flush mounting boxes. To complete with 7-module cover plate

产品状态
2 - Will be discontinued

Class group
Luminaires
Class
Emergency luminaire
Mounting method
Built-in
Monitoring equipment
None
With remote switch connection
No
Power supply system
Peripheral (individual battery)
Battery quality
NiCd
Lamp type
Fluorescent lamp
With light source
Yes
Housing material
Plastic
Housing colour
White
Material cover
Without cover
Voltage type
AC
Nominal voltage
230,00 - 230,01 V
Degree of protection (IP)
IP40
Protection class
II
Max. system power
4,00 W
Rated luminous flux according to IEC 62722-2-1
26
Width
203,40 mm
Height/depth
74,00 mm
Built-in width
203,40 mm
Built-in height/depth
47,10 mm

00. CE Marking - EU

17. ENEC 03 (IMQ)

37. Marking - Morocco

43. UKCA mark - Great Britain

96. Electrotechnical expert

99. WEEE Directive

最小订单数量: 1 NR

条形码

Barcode Qty 1 NR
8007352117693
1 NR
21.4x6.6x9.3 [cm]
470.34 [g]
问题： On the 16440 Idea and 14394 Plana emergency lighting fitting, the green LED occasionally flashes, is this normal?
回答： Yes, the operation of this device is such that the green LED flashes for about three minutes every hour to indicate that rapid battery recharging is in progress, in order to maintain the maximum degree of efficiency.
