1P+N C10 CB 120-230V Silver - 14405.10.SL

Pdf
14405.10.SL

Plana Silver / Devices / Current breaker switches (CBs)

1P+N C10 CB 120-230V Silver
1P+N C 10 circuit breaker, supply voltage 120-230 V~ 50-60 Hz, breaking capacity 3000 A, dissipated power 1 W, Silver

产品状态
3 - Active

Class group
Circuit breakers and fuses
Class
Miniature circuit breaker (MCB)
Release characteristic
C
Number of poles (total)
2
Number of protected poles
1
Rated current
10 A
Rated voltage
230 v
Rated short-circuit breaking capacity Icn EN 60898 at 230 V
3,00 kA
Voltage type
AC
Frequency
50 - 60 HZ
Current limiting class
1
Suitable for flush-mounted installation
Yes
Concurrently switching N-neutral
Yes
Over voltage category
3
Width in number of modular spacings
1
Built-in depth
38,00 mm
Degree of protection (IP)
IP40
最小订单数量: 10 NR

条形码

Barcode Qty 1 NR
8007352311725
1 NR
6x2.8x5.3 [cm]
55.11 [g]
Barcode Qty 10 NR
8007352311732
10 NR
14.4x13.1x6 [cm]
600.07 [g]
