Vertical badge switch 2M Silver - 14463.SL

Pdf
14463.SL

Plana Silver / Systems / Access control system

Vertical badge switch 2M Silver
Upright electronic badge switch, 4 A 250 V~ NO (NON SELV) change-over relay output, power supply 120-230 V~ 50-60 Hz, slot lighting for location in the dark, trimmer for regulating switch-off time after removing the card, Silver - 2 modules. Supplied without ISO card (badge)

产品状态
3 - Active

Class group
Alarm installations, emergency call and signalling
Class
Access control system
Standalone
Yes
Networkable
No
PC-binding
No
Type of interface
None
Reading strategy
Data medium
Signalling
None
Mounting method
Flush mounted (plaster)
Operating voltage at AC 50 Hz
250,00 - 250,01 v
Operating voltage at AC 60 Hz
250,00 - 250,01 v
Operating temperature
-5 - 35 °C
Degree of protection (IP)
IP20
Colour
Silver
Material
Plastic
Width
44,80 mm
Height
49,00 mm
Depth
43,50 mm
最小订单数量: 1 NR

条形码

Barcode Qty 1 NR
8007352563711
1 NR
5.2x5.7x7.6 [cm]
69 [g]
Barcode Qty 5 NR
8007352563728
5 NR
21.4x11.6x6 [cm]
402.7 [g]
