Rolling shutter IoT connected mechanism代码 14594.0
- 14594.0
- Wiring devices / View Wireless wiring devices / PLANA / Devices
- Rolling shutter IoT connected mechanism
- View Wireless connected electronic control device for 1 roller shutter with slat orientation and change-over relay output for cosφ 0,6 motor 2 A 100-240 V~ 50/60 Hz, local or remote control, double technology with Bluetooth® wireless technology 5.0 standard for the realization of View Wireless mesh system andZigbee 3.0 standard, 1 input for external push button to recall a scenario, favourite position recall function, RGB LED visible in darkness with brightness control, 100-240 V 50/60 Hz power supply, to be completed with two interchangeable 1-module Plana half-buttons
- Configuration from View Wireless App for Bluetooth technology system and Amazon App for Zigbee technology
- Compatible with Alexa, Google Home and IFTTT, using the dedicated gateway or Zigbee hub
- Compatible with SmartThings hub
- 产品状态
- 3 - Active
您可能也感兴趣
单, 说明书, 文档
- Light multilanguage instructions sheet (938 kb)
- Foglio istruzioni Full (519 kb)
- Feuille d’instructions Full (508 kb)
- Hoja de instrucciones Full (507 kb)
- Full instructions sheet (503 kb)
- Φυλλάδιο οδηγιών Full (645 kb)
- Anweisungsblatt Full (506 kb)
- ورقة الإرشادات Full (574 kb)
- Manuale app View Wireless (19698 kb)
- Manuel appli View Wireless (42466 kb)
- Manual app View Wireless (42466 kb)
- Manual View Wireless app (42593 kb)
- Εγχειρίδιο τεχνικού εγκατάστασης (42754 kb)
- Installationsanleitung View Wireless (42520 kb)
图纸
Class group
Installation bus systems
Installation bus systems
Class
Shutting actuator for bus system
Shutting actuator for bus system
Bus system KNX
No
No
Bus system KNX-RF (Radio Frequency)
No
No
Bus system radio frequency
Yes
Yes
Bus system LON
No
No
Bus system Powernet
No
No
Other bus systems
Zigbee
Zigbee
Mounting method
Built-in
Built-in
Width in number of modular spacings
0
0
Local operation/hand operation
Yes
Yes
With LED indication
Yes
Yes
37. Marking - Morocco
37. Marking - Morocco
37. Marking - Morocco
40. Bluetooth technology
42. Zigbee certified
47. Works with SmartThings
最小订单数量: 1 NR
条形码

8007352628540
1 NR
5.2x3.5x5.3 [cm]
44.8 [g]

8007352628557
60 NR
27x23x12.5 [cm]
2,869 [g]
| 问题: | After I have set the device as Zigbee, how can I reset the device to Bluetooth mode? |
|---|---|
| 回答: | The procedure allowing the conversion of the operating mode/technology on the product in question can be found inside the ˝VIEW Wireless˝ App in the menu: ˝Actions -> Manage device˝. |
| 问题: | Can the product in question be used for roller shutters without adjustable slats? |
| 回答: | The product in question, if used in BLE (Bluetooth Low Energy) mode and configured using the VIEW Wireless App, envisages on this application the possibility of setting the device to operate as ˝roller shutter without slats˝. |
| 问题: | Is there a substantial difference between product 14594 and 14594.0? |
| 回答: | The only difference between 14594 and 14594.0 is that the first code also envisages the integrated button covers, making it already directly ready for installation. |
