Frame 2M +claws 57mm

Pdf

14604
Wiring devices / Traditional wiring devices / PLANA / Mounting frames

Frame 2M +claws 57mm
2-module mounting frame, with claws, for ø 60 mm mounting boxes, modular, 57 mm distance between centres

产品状态
3 - Active

图纸

PNG DXF

Class group
Domestic switching devices

Class
Holder for modular domestic switching devices

Model
Flush-mounted

Mounting method
Mounting with claw

Mounting method of the module inserts
Front side

Mounting direction
Horizontal and vertical

Number of modules horizontal (module system)
2

Number of modules vertical (module system)
1

With built-in installation box
No

With screws
No

Suitable for mounting in round junction box 60 mm
Yes

Flush-mounted installation
Yes

Suitable for subfloor installation duct box
No

Suitable for wall duct
No

Suitable for mounting on DIN-rail 35 mm
No

Material
Plastic

Material quality
Thermoplastic

00. CE Marking - EU

01. IMQ - Italy

29. QCERT - Colombia

43. UKCA mark - Great Britain

96. Electrotechnical expert

最小订单数量: 20 NR

条形码

8007352118973

1 NR

7.16x6.06x2.5 [cm]

18.13 [g]

8007352118980

20 NR

24.4x13.9x8.4 [cm]

441.87 [g]

8007352642355

200 NR

47.5x27x29 [cm]

4,920 [g]

合法

Vimar保留随时修改所示产品的特性的权利，恕不另行通知。安装必须由符合资质的人员执行，严格遵守所在国家现行的电气材料安装相关规定。有关产品卡信息的使用条件，请参阅使用条件。
