Frame 2centralM +screws - 14612

Pdf

14612
Wiring devices / Traditional wiring devices / PLANA / Mounting frames

Frame 2centralM +screws
2-central-module mounting frame, with screws, for 3-module mounting boxes or boxes with 60 mm fixing centres or 56x56 mm, for horizontal or vertical installation

  • The transparency helps the installation and the wiring of devices
  • The honeycomb structure gives structural strength
  • The slots in the corners enable fixing to the panel
  • The hooking teeth encourage fixing in series for the installation of multiple modules
  • Thanks to the central slots, the support can be fixed onto the wall level

产品状态
3 - Active

您可能也感兴趣

图纸

Class group
Domestic switching devices
Class
Holder for modular domestic switching devices
Model
Flush-mounted
Mounting method
Mounting with screw
Mounting method of the module inserts
Front side
Mounting direction
Horizontal and vertical
Number of modules horizontal (module system)
2
Number of modules vertical (module system)
1
With built-in installation box
No
With screws
Yes
Suitable for mounting in round junction box 60 mm
No
Flush-mounted installation
Yes
Suitable for subfloor installation duct box
No
Suitable for wall duct
No
Suitable for mounting on DIN-rail 35 mm
No
Material
Plastic
Material quality
Thermoplastic

00. CE Marking - EU

29. QCERT - Colombia

43. UKCA mark - Great Britain

最小订单数量: 20 NR

条形码

Barcode Qty 1 NR
8007352122581
1 NR
8.35x6x1.5 [cm]
25.89 [g]
Barcode Qty 20 NR
8007352122598
20 NR
24.4x13.9x11.9 [cm]
614.87 [g]
Barcode Qty 240 NR
8007352368880
240 NR
59.5x38.5x26.5 [cm]
8,178.44 [g]
