Frame 3M +screws - 14613

Pdf

14613
Wiring devices / Traditional wiring devices / PLANA / Mounting frames

Frame 3M +screws
3-module mounting frame, with screws, for 3-module mounting boxes

产品状态
3 - Active

您可能也感兴趣

图纸

Class group
Domestic switching devices
Class
Holder for modular domestic switching devices
Model
Flush-mounted
Mounting method
Mounting with screw
Mounting method of the module inserts
Front side
Mounting direction
Horizontal and vertical
Number of modules horizontal (module system)
3
Number of modules vertical (module system)
1
With built-in installation box
No
With screws
Yes
Suitable for mounting in round junction box 60 mm
No
Flush-mounted installation
Yes
Suitable for subfloor installation duct box
No
Suitable for wall duct
No
Suitable for mounting on DIN-rail 35 mm
No
Material
Plastic
Material quality
Thermoplastic

00. CE Marking - EU

29. QCERT - Colombia

43. UKCA mark - Great Britain

50. Product Environm. Profile

最小订单数量: 200 NR

条形码

Barcode Qty 1 NR
8007352108219
1 NR
11.8x7.4x2.2 [cm]
23.53 [g]
Barcode Qty 10 NR
8007352147263
10 NR
11.8x7.46x15.2 [cm]
237.87 [g]
Barcode Qty 200 NR
8007352147270
200 NR
38x34x24 [cm]
5,303.33 [g]
Barcode Qty 6,400 NR
8007352263413
6,400 NR
80x120x127 [cm]
175,000 [g]
