Frame 4M +screws - 14614

Pdf

14614
Wiring devices / Traditional wiring devices / PLANA / Mounting frames

Frame 4M +screws
4-module mounting frame, with screws, for 4-module mounting boxes

产品状态
3 - Active

您可能也感兴趣

图纸

Class group
Domestic switching devices
Class
Holder for modular domestic switching devices
Model
Flush-mounted
Mounting method
Mounting with screw
Mounting method of the module inserts
Front side
Mounting direction
Horizontal and vertical
Number of modules horizontal (module system)
4
Number of modules vertical (module system)
1
With built-in installation box
No
With screws
Yes
Suitable for mounting in round junction box 60 mm
No
Flush-mounted installation
Yes
Suitable for subfloor installation duct box
No
Suitable for wall duct
No
Suitable for mounting on DIN-rail 35 mm
No
Material
Plastic
Material quality
Thermoplastic

00. CE Marking - EU

29. QCERT - Colombia

43. UKCA mark - Great Britain

最小订单数量: 40 NR

条形码

Barcode Qty 1 NR
8007352108240
1 NR
14.05x7.43x2.17 [cm]
26.93 [g]
Barcode Qty 40 NR
8007352108257
40 NR
28.4x24.4x16.4 [cm]
1,268.27 [g]
Barcode Qty 160 NR
8007352361430
160 NR
59.5x38.5x26.5 [cm]
5,873.08 [g]
Barcode Qty 1,920 NR
8007352482470
1,920 NR
80x120x93.5 [cm]
70,476.96 [g]
