Wiring devices / Traditional wiring devices / PLANA / Mounting frames
Frame 7M +screws
7-module mounting frame, with screws, for 6/7-module mounting boxes
产品状态
3 - Active
您可能也感兴趣
图纸
Class group
Domestic switching devices
Domestic switching devices
Class
Holder for modular domestic switching devices
Holder for modular domestic switching devices
Model
Flush-mounted
Flush-mounted
Type of fastening
Other
Other
Mounting method of the module inserts
Front side
Front side
Mounting direction
Horizontal and vertical
Horizontal and vertical
Number of modules horizontal (module system)
7
7
Number of modules vertical (module system)
1
1
With built-in installation box
No
No
With screws
Yes
Yes
Suitable for mounting in round junction box 60 mm
No
No
Flush-mounted installation
Yes
Yes
Suitable for subfloor installation duct box
No
No
Suitable for wall duct
No
No
Suitable for mounting on DIN-rail 35 mm
No
No
Material
Plastic
Plastic
Material quality
Thermoplastic
Thermoplastic
最小订单数量: 30 NR
条形码
8007352108967
1 NR
20.34x7.38x2.18 [cm]
35.43 [g]
8007352108974
30 NR
28.4x24.4x14.9 [cm]
1,261 [g]
8007352361447
120 NR
62x26x30 [cm]
5,774 [g]
