14620
Wiring devices / Traditional wiring devices / PLANA / Mounting frames
Frame 14M +screws
14 (7+7)-module mounting frame, with screws, for V71320, V71620 and V71720 flush or 09920 surface mounting boxes
产品状态
3 - Active
您可能也感兴趣
图纸
Class group
Domestic switching devices
Domestic switching devices
Class
Holder for modular domestic switching devices
Holder for modular domestic switching devices
Model
Flush-mounted
Flush-mounted
Type of fastening
Other
Other
Mounting method of the module inserts
Front side
Front side
Mounting direction
Horizontal and vertical
Horizontal and vertical
Number of modules horizontal (module system)
7
7
Number of modules vertical (module system)
2
2
With built-in installation box
No
No
With screws
Yes
Yes
Suitable for mounting in round junction box 60 mm
No
No
Flush-mounted installation
Yes
Yes
Suitable for subfloor installation duct box
No
No
Suitable for wall duct
No
No
Suitable for mounting on DIN-rail 35 mm
No
No
Material
Plastic
Plastic
Material quality
Thermoplastic
Thermoplastic
最小订单数量: 10 NR
条形码
8007352116955
1 NR
20.34x14.6x2.7 [cm]
91.21 [g]
8007352116962
10 NR
28.4x24.4x13.4 [cm]
1,081.73 [g]
