Vimar - 16016.F - 2P 16AX 1-way switch luminescent grey

16016.F
Wiring devices / Traditional wiring devices / IDEA / Devices

2P 16AX 1-way switch luminescent grey
2P 16 AX 250 V~ 1-way switch, with luminescent indicator, grey

产品状态
2 - Will be discontinued

图纸

PNG DXF

Class group
Domestic switching devices

Class
Installation switch

Wiring system
2-pole switch

Method of operation
Rocker/button

Assembly arrangement
Modular device for domestic switching devices

Number of modules (module system)
1

Push button switch
Yes

Number of rockers
1

Mounting method
Flush-mounted

Type of fastening
Engage (snap)

With mounting plate
No

Material
Plastic

Material quality
Thermoplastic

Halogen free
Yes

Surface protection
Untreated

Surface finishing
Matt

Colour
Grey

RAL-number (similar)
7015

Label space/information surface
Yes

Illumination
No

Function lighting
Other

Type of lighting
Other

Suitable for degree of protection (IP)
IP40

Nominal voltage
250 V

Rated current
16,00 A

Feedback-signal contact
No

Connection type
Screwed terminal

Washing machine switch
Yes

Device width
24,80 mm

Device height
50,10 mm

Device depth
39,30 mm

Built-in depth
25,50 mm

00. CE Marking - EU

01. IMQ - Italy

14. TSE - Turkey

15. CCC - China

37. Marking - Morocco

96. Electrotechnical expert

99. WEEE Directive

最小订单数量: 20 NR

条形码

8007352000797

1 NR

5.1x2.8x5.3 [cm]

35.4 [g]

8007352001282

20 NR

27x11.6x6 [cm]

780.2 [g]

合法
