1P 16AX 1-way switch luminous 3M white - 16021.G.B

Pdf

16021.G.B
Wiring devices / Traditional wiring devices / IDEA / Devices

1P 16AX 1-way switch luminous 3M white
1P 16 AX 250 V~ 1-way switch, luminous, for signalling unit, white - 3 modules. Provided without signalling unit. Max 200 W for self-ballasted lamps (IEC 60669-1:2017)

产品状态
2 - Will be discontinued

Class group
Domestic switching devices
Class
Installation switch
Wiring system
Off switch 1-pole
Method of operation
Rocker/button
Assembly arrangement
Modular device for domestic switching devices
Number of modules (module system)
3
Push button switch
Yes
Number of rockers
1
Mounting method
Flush-mounted
Type of fastening
Engage (snap)
With mounting plate
No
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Untreated
Surface finishing
Matt
Colour
White
RAL-number (similar)
9001
Label space/information surface
Yes
Illumination
Optional
Function lighting
Control and orientation
Type of lighting
LED exchangeable
Suitable for degree of protection (IP)
IP40
Nominal voltage
250 V
Rated current
16,00 A
Feedback-signal contact
No
Connection type
Screwed terminal
Washing machine switch
No
Device width
24,80 mm
Device height
50,10 mm
Device depth
36,50 mm
Built-in depth
23,30 mm

00. CE Marking - EU

01. IMQ - Italy

19. NOM - Mexico

37. Marking - Morocco

43. UKCA mark - Great Britain

最小订单数量: 20 NR

条形码

Barcode Qty 1 NR
8007352090699
1 NR
5.3x3.9x7.6 [cm]
46.53 [g]
Barcode Qty 20 NR
8007352090705
20 NR
28.1x13.1x11.3 [cm]
1,036.53 [g]
