1P NO 10A push general symb.lums 3M grey

Pdf

Vimar - 16090.G - 1P NO 10A push general symb.lums 3M grey

16090.G
Wiring devices / Traditional wiring devices / IDEA / Devices

1P NO 10A push general symb.lums 3M grey
1P NO 10 A 250 V~push button, general symbol, luminous, for signalling unit, grey - 3 modules. Provided without signalling unit

产品状态
2 - Will be discontinued

Class group
Domestic switching devices

Class
Push button

Assembly arrangement
Modular device for domestic switching devices

Model
Single push button

Method of operation
Push button

Number of rockers
1

Number of modules (module system)
300

Number of poles
1

Nominal voltage
250 V

Rated current
10,00 A

With lighting
Yes

Feedback-signal contact
No

Mounting method
Flush-mounted

Type of fastening
Engage (snap)

Material
Plastic

Material quality
Thermoplastic

Halogen free
Yes

Surface protection
Untreated

Surface finishing
Matt

Colour
Grey

RAL-number (similar)
7015

Transparent
No

Label space/information surface
Yes

Suitable for degree of protection (IP)
IP40

Device width
24,80 mm

Device height
50,10 mm

Device depth
36,10 mm

00. CE Marking - EU

01. IMQ - Italy

14. TSE - Turkey

15. CCC - China

19. NOM - Mexico

37. Marking - Morocco

96. Electrotechnical expert

99. WEEE Directive

最小订单数量: 20 NR

条形码

8007352090750

1 NR

5.3x3.9x7.6 [cm]

46.53 [g]

8007352090767

20 NR

28.1x13.1x11.3 [cm]

1,033.87 [g]

合法

Vimar保留随时修改所示产品的特性的权利，恕不另行通知。安装必须由符合资质的人员执行，严格遵守所在国家现行的电气材料安装相关规定。有关产品卡信息的使用条件，请参阅使用条件。
