Vimar - 16092 - 1P NC 10A push general symbol lums grey
Vimar - 16092 - 1P NC 10A push general symbol lums grey
16092

Idea / Devices / Devices - other functions

1P NC 10A push general symbol lums grey
1P NC 10 A 250 V~ push button, general symbol, luminous, for signalling unit, grey. Provided without signalling unit

产品状态
3 - Active

Class group
Domestic switching devices
Class
Push-switch button
Assembly arrangement
Modular device for domestic switching devices
Model
Single push button
Method of operation
Push button
Number of rockers
1
Number of modules (module system)
1
Number of poles
1
Nominal voltage
250 v
Rated current
10,00 A
With lighting
Yes
Feedback-signal contact
No
Mounting method
Flush mounted (plaster)
Type of fastening
Engage (snap)
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Untreated
Surface finishing
Matt
Colour
Grey
RAL-number (similar)
7015
Transparent
No
Label space/information surface
Yes
Suitable for degree of protection (IP)
IP40
Width of device
24,80 mm
Height of device
50,10 mm
Depth of device
36,10 mm

00. CE Marking - EU

01. IMQ - Italy

01. IMQ - Italy

10. EAC Eurasian Customs Union

14. TSE - Turkey

19. NOM - Mexico

20. IRAM - Argentina

28. NSW / RCM - Australia

37. Marking - Morocco

96. Electrotechnical expert

99. WEEE Directive

最小订单数量: 20 NR

条形码

Barcode Qty 1 NR
8007352099586
1 NR
4.1x2.8x5.3 [cm]
27.4 [g]
Barcode Qty 20 NR
8007352099593
20 NR
21.4x11.6x6 [cm]
611.8 [g]
Barcode Qty 300 NR
8007352644847
300 NR
37x28.5x25 [cm]
9,612 [g]
