1P NC 10A push general symbol lums white - 16092.B

Pdf

16092.B
Wiring devices / Traditional wiring devices / IDEA / Devices

1P NC 10A push general symbol lums white
1P NC 10 A 250 V~ push button, general symbol, luminous, for signalling unit, white. Provided without signalling unit

产品状态
3 - Active

图纸

Class group
Domestic switching devices
Class
Push button
Assembly arrangement
Modular device for domestic switching devices
Model
Single push button
Method of operation
Push button
Number of rockers
1
Number of modules (module system)
100
Number of poles
1
Nominal voltage
250 V
Rated current
10,00 A
With lighting
Yes
Feedback-signal contact
No
Mounting method
Flush-mounted
Type of fastening
Engage (snap)
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Untreated
Surface finishing
Matt
Colour
White
RAL-number (similar)
9001
Transparent
No
Label space/information surface
Yes
Suitable for degree of protection (IP)
IP40
Device width
24,80 mm
Device height
50,10 mm
Device depth
36,10 mm

00. CE Marking - EU

01. IMQ - Italy

19. NOM - Mexico

20. IQC - Argentina

37. Marking - Morocco

43. UKCA mark - Great Britain

最小订单数量: 20 NR

条形码

Barcode Qty 1 NR
8007352099609
1 NR
4.1x2.8x5.3 [cm]
27.47 [g]
Barcode Qty 20 NR
8007352099616
20 NR
21.4x11.6x6 [cm]
610.13 [g]
