16165.CU.B
Wiring devices / Traditional wiring devices / IDEA / Devices
2P 16(3)A 1-way switch +000-key white
Independent mounting 2P 16(3) A 250 V~ key-operated 1-way switch, with 000 unified key, white. To be installed with the appropriate accessories from the Idea series. Protection degree: IP20, Degree of pollution: II, Overvoltage category: III, for conductors from 1.5 mm2 to 4 mm2, complete circuit disconnection, Tracking index: PTI250, Glow wire 850°C
产品状态
3 - Active
Class group
Domestic switching devices
Domestic switching devices
Class
Installation switch
Installation switch
Wiring system
2-pole switch
2-pole switch
Method of operation
Key
Key
Assembly arrangement
Other
Other
Number of modules (module system)
1
1
Push button switch
Yes
Yes
Number of rockers
0
0
Mounting method
Flush-mounted
Flush-mounted
Type of fastening
Engage (snap)
Engage (snap)
With mounting plate
No
No
Material
Plastic
Plastic
Material quality
Thermoplastic
Thermoplastic
Halogen free
Yes
Yes
Surface protection
Untreated
Untreated
Surface finishing
Matt
Matt
Colour
White
White
RAL-number (similar)
9001
9001
Label space/information surface
Yes
Yes
Lighting
No
No
Function lighting
Other
Other
Type of lighting
Other
Other
Suitable for degree of protection (IP)
IP40
IP40
Nominal voltage
250 V
250 V
Rated current
16,00 A
16,00 A
Monitoring contact
No
No
Connection type
Screwed terminal
Screwed terminal
Washing machine switch
Yes
Yes
Device width
24,80 mm
24,80 mm
Device height
50,10 mm
50,10 mm
Device depth
32,80 mm
32,80 mm
Built-in depth
32,80 mm
32,80 mm
00. CE Marking - EU
14. TSE - Turkey
20. IQC - Argentina
37. Marking - Morocco
最小订单数量: 20 NR
条形码
8007352067608
1 NR
5.1x2.8x5.3 [cm]
52.27 [g]
8007352067615
20 NR
27x11.6x6 [cm]
1,112.8 [g]
