Univ.MASTER rotary-dimmer 230V grey - 16603.1

Pdf

Vimar - 16603.1 - Univ.MASTER rotary-dimmer 230V grey

16603.1
Wiring devices / Traditional wiring devices / IDEA / Devices

Univ.MASTER rotary-dimmer 230V grey
Universal phase cutting dimmer 230 V~ 50 Hz, for 40-400 W incandescent lamps, 40-300 VA electronic transformers, 10-200 W CFL lamps, 3-200 W LED lamps, for LED phase cutting electronic power supply units, ON/OFF control with built-in push button or via NO peripheral push buttons, dimming with built-in rotary potentiometer, minimum brightness control, visible in darkness, grey. Device not suiTable for installation in Isoset enclosures

产品状态
3 - Active

单, 说明书, 文档

Multilanguage instructions sheet (2356 kb)

图纸

PNG DXF

PNG DXF

PNG DXF

Class group
Domestic switching devices

Class
Dimmer

Method of operation
Turn button

Type of load
Universal and LED Retrofit

Applicable with button
Yes

Applicable with movement sensor
No

Applicable with presence indicator
No

Applicable with time switch/timer
No

Applicable with transmission button
No

Applicable with infrared button
No

Mounting method
Flush-mounted

Type of fastening
Snapper mounting

Material
Plastic

Material quality
Thermoplastic

Surface protection
Untreated

Surface finishing
Matt

Colour
Grey

RAL-number (similar)
9001

Transparent
No

Suitable for degree of protection (IP)
IP40

Nominal voltage
230,00 - 230,01 V

Frequency
50,00 - 50,01 HZ

Control voltage
230,00 - 230,01 V

Connection type
Screwed terminal

Device width
24,80 mm

Device height
50,10 mm

Device depth
60,40 mm

00. CE Marking - EU

37. Marking - Morocco

43. UKCA mark - Great Britain

99. WEEE Directive

最小订单数量: 10 NR

条形码

8007352555754

1 NR

5.2x3.9x6.2 [cm]

57.7 [g]

8007352555761

10 NR

20.5x11.5x7 [cm]

641.5 [g]
