Frame 3M +screws - 16713

Pdf

16713
Wiring devices / Traditional wiring devices / IDEA / Mounting frames

Frame 3M +screws
3-module mounting frame, with screws, for 3-module mounting boxes, grey

产品状态
3 - Active

您可能也感兴趣

图纸

Class group
Domestic switching devices
Class
Holder for modular domestic switching devices
Model
Flush-mounted
Mounting method
Mounting with screw
Mounting method of the module inserts
Back side
Mounting direction
Horizontal and vertical
Number of modules horizontal (module system)
3
Number of modules vertical (module system)
1
With built-in installation box
No
With screws
Yes
Suitable for mounting in round junction box 60 mm
No
Flush-mounted installation
Yes
Suitable for subfloor installation duct box
No
Suitable for wall duct
No
Suitable for mounting on DIN-rail 35 mm
No
Material
Plastic
Material quality
Thermoplastic

00. CE Marking - EU

43. UKCA mark - Great Britain

最小订单数量: 20 NR

条形码

Barcode Qty 1 NR
8007352045477
1 NR
11.4x7.5x1.5 [cm]
22.6 [g]
Barcode Qty 10 NR
8007352147249
10 NR
11.4x7.5x15 [cm]
228.13 [g]
Barcode Qty 20 NR
8007352631410
20 NR
28.4x18.4x7.5 [cm]
456.26 [g]
Barcode Qty 240 NR
8007352631427
240 NR
59x38.5x24 [cm]
7,220 [g]
Barcode Qty 7,680 NR
8007352654402
7,680 NR
120x80x185 [cm]
190,924.8 [g]
问题: Are the Idea Rondo plaques compatible with the devices and mounting supports of the Idea Classic plaques?
回答: The Idea series has devices and mounting supports that can be completed with both Classic plaques and Rondo plaques. The Rondo plaques are not compatible with the following parts (thus require Classic plaques):-16803 and 16806 table mounting box-16813 mounting bracket-09975.A surface mounting box-16570.SZ and 16570.SZ.B mounting support for infrared remote control.
