Vimar - 16714 - Frame 4M +screws
Vimar - 16714 - Frame 4M +screws

16714
Wiring devices / Traditional wiring devices / IDEA / Mounting frames

Frame 4M +screws
4-module mounting frame, with screws, for 4-module mounting boxes, grey

产品状态
3 - Active

您可能也感兴趣

07937
07937 - Screw for frame fixing - 35mm
07939
07939 - Screw for frame fixing - 50 mm

图纸

PNG DXF
PNG DXF
PNG DXF
Class group
Domestic switching devices
Class
Holder for modular domestic switching devices
Model
Flush-mounted
Mounting method
Mounting with screw
Mounting method of the module inserts
Back side
Mounting direction
Horizontal and vertical
Number of modules horizontal (module system)
4
Number of modules vertical (module system)
1
With built-in installation box
No
With screws
Yes
Suitable for mounting in round junction box 60 mm
No
Flush-mounted installation
Yes
Suitable for subfloor installation duct box
No
Suitable for wall duct
No
Suitable for mounting on DIN-rail 35 mm
No
Material
Plastic
Material quality
Thermoplastic

00. CE Marking - EU

01. IMQ - Italy

15. CCC - China

43. UKCA mark - Great Britain

96. Electrotechnical expert

最小订单数量: 20 NR

条形码

Barcode Qty 1 NR
8007352045484
1 NR
14.3x7.5x2.1 [cm]
25.85 [g]
Barcode Qty 20 NR
8007352000032
20 NR
28.4x18.4x9.5 [cm]
640 [g]
Barcode Qty 240 NR
8007352263246
240 NR
59x38.5x30 [cm]
8,620 [g]
Barcode Qty 2,880 NR
8007352482524
2,880 NR
80x120x103 [cm]
103,449 [g]
