Wiring devices / Traditional wiring devices / IDEA / Mounting frames
Frame 18M +screws
18 (6+6+6)-module mounting frame, with screws, for flush mounting box V71321 or surface mounting box 09921, grey
产品状态
3 - Active
您可能也感兴趣
图纸
Class group
Domestic switching devices
Domestic switching devices
Class
Holder for modular domestic switching devices
Holder for modular domestic switching devices
Model
Flush-mounted
Flush-mounted
Type of fastening
Other
Other
Mounting method of the module inserts
Back side
Back side
Mounting direction
Horizontal and vertical
Horizontal and vertical
Number of modules horizontal (module system)
6
6
Number of modules vertical (module system)
3
3
With built-in installation box
No
No
With screws
Yes
Yes
Suitable for mounting in round junction box 60 mm
No
No
Flush-mounted installation
Yes
Yes
Suitable for subfloor installation duct box
No
No
Suitable for wall duct
No
No
Suitable for mounting on DIN-rail 35 mm
No
No
Material
Plastic
Plastic
Material quality
Thermoplastic
Thermoplastic
最小订单数量: 10 NR
条形码
8007352117013
1 NR
18x20x2.1 [cm]
119.6 [g]
8007352117020
10 NR
28.4x24.4x16.4 [cm]
1,411.47 [g]
