Frame 2M grooved front grey - 16722

Pdf
Vimar - 16722 - Frame 2M grooved front grey
Vimar - 16722 - Frame 2M grooved front grey

16722
Wiring devices / Traditional wiring devices / IDEA / Mounting frames

Frame 2M grooved front grey
2-module mounting frame, grooved front, without screws, for 3-module and 60 mm fixing centres or 56x56 mm mounting boxes, grey

产品状态
3 - Active

您可能也感兴趣

16713.C
16713.C - Protective cover for 16713
07937
07937 - Screw for frame fixing - 35mm
07939
07939 - Screw for frame fixing - 50 mm

图纸

PNG DXF
PNG DXF
PNG DXF
Class group
Domestic switching devices
Class
Holder for modular domestic switching devices
Model
Flush-mounted
Mounting method
Mounting with screw
Mounting method of the module inserts
Back side
Mounting direction
Horizontal and vertical
Number of modules horizontal (module system)
2
Number of modules vertical (module system)
1
With built-in installation box
No
With screws
No
Suitable for mounting in round junction box 60 mm
No
Flush-mounted installation
Yes
Suitable for subfloor installation duct box
No
Suitable for wall duct
No
Suitable for mounting on DIN-rail 35 mm
No
Material
Plastic
Material quality
Thermoplastic

00. CE Marking - EU

01. IMQ - Italy

15. CCC - China

43. UKCA mark - Great Britain

96. Electrotechnical expert

最小订单数量: 20 NR

条形码

Barcode Qty 1 NR
8007352047334
1 NR
12.2x3x2 [cm]
27.11 [g]
Barcode Qty 20 NR
8007352047341
20 NR
24.4x13.9x11.9 [cm]
646.2 [g]
