Frame 3M Arké idea+screws grey - 16723, For rectangular boxes, Idea - 产品目录

Pdf

16723

Idea / Mounting frames / For rectangular boxes

Frame 3M Arké idea+screws grey
3-module mounting frame, with screws, for 2-module Arké devices installation on Idea cover plates, for 3-module mounting boxes, grey

产品状态
3 - Active

您可能也感兴趣

07937 - Screw for frame fixing - 35mm

07939 - Screw for frame fixing - 50 mm

图纸

PNG DXF

Class group
Domestic switching devices

Class
Holder for modular domestic switching devices

Model
Flush mounted (plaster)

Mounting method
Mounting with screw

Mounting method of the module inserts
Front side

Mounting direction
Horizontal and vertical

Number of modules horizontal (module system)
3

Number of modules vertical (module system)
1

With built-in installation box
No

With screws
Yes

Suitable for mounting in round junction box 60 mm
No

Flush-mounted installation
Yes

Suitable for floor box
No

Suitable for wall duct
No

Suitable for mounting on DIN-rail 35 mm
No

Material
Plastic

Material quality
Thermoplastic

00. CE Marking - EU

01. IMQ - Italy

15. CCC - China

29. QCERT - Colombia

37. Marking - Morocco

43. UKCA mark - Great Britain

96. Electrotechnical expert

最小订单数量: 20 NR

条形码

8007352533820

1 NR

11.8x7.5x2.5 [cm]

22.2 [g]

8007352533837

20 NR

28x15.2x9.75 [cm]

536 [g]

问题：	The timer-thermostat replacing an Idea thermostat 16580 will not adapt to the cover plate for surface mounting.
回答：	In order to install the Idea cover plate, simply purchase the mounting frame code 16723 - Arké Idea 3M mounting frame + grey screws.
