Vimar - 17003.L.B - 1P 16AX 2-way switch lums white

17003.L.B
Wiring devices / Traditional wiring devices / IDEA / Devices

1P 16AX 2-way switch lums white
1P 16 AX 250 V~ 2-way switch, luminous, for signalling unit, white - reduced module. Provided without signalling unit. Max 200 W for self-ballasted lamps (IEC 60669-1:2017)

产品状态
3 - Active

Class group
Domestic switching devices

Class
Installation switch

Wiring system
Two-way switch

Method of operation
Rocker/button

Assembly arrangement
Modular device for domestic switching devices

Number of modules (module system)
1

Push button switch
Yes

Number of rockers
1

Mounting method
Flush-mounted

Type of fastening
Engage (snap)

With mounting plate
No

Material
Plastic

Material quality
Thermoplastic

Halogen free
Yes

Surface protection
Untreated

Surface finishing
Matt

Colour
White

RAL-number (similar)
9001

Label space/information surface
Yes

Illumination
Optional

Function lighting
Control and orientation

Type of lighting
LED exchangeable

Suitable for degree of protection (IP)
IP40

Nominal voltage
250 V

Rated current
16,00 A

Feedback-signal contact
No

Connection type
Screwed terminal

Washing machine switch
No

Device width
21,80 mm

Device height
50,10 mm

Device depth
32,50 mm

Built-in depth
23,30 mm

00. CE Marking - EU

01. IMQ - Italy

10. EAC Eurasian Customs Union

14. TSE - Turkey

15. CCC - China

19. NOM - Mexico

28. NSW - Australia

37. Marking - Morocco

43. UKCA mark - Great Britain

96. Electrotechnical expert

99. WEEE Directive

最小订单数量: 20 NR

条形码

8007352078420

1 NR

4.1x2.8x5.3 [cm]

27.27 [g]

8007352078437

20 NR

21.4x11.6x6 [cm]

604.13 [g]

合法
