17080.B

Idea / Mounting frames / For round boxes

Frame 1M smooth front+claws white
1-module mounting frame, smooth front, with claws, for ø 60 mm round flush or 09971 surface mounting boxes, white

产品状态
3 - Active

图纸

PNG DXF

Class group
Domestic switching devices

Class
Holder for modular domestic switching devices

Model
Flush mounted (plaster)

Mounting method
Mounting with claw

Mounting method of the module inserts
Back side

Mounting direction
Horizontal and vertical

Number of modules horizontal (module system)
1

Number of modules vertical (module system)
1

With built-in installation box
No

With screws
No

Suitable for mounting in round junction box 60 mm
Yes

Flush-mounted installation
Yes

Suitable for floor box
No

Suitable for wall duct
No

Suitable for mounting on DIN-rail 35 mm
No

Material
Plastic

Material quality
Thermoplastic

00. CE Marking - EU

01. IMQ - Italy

37. Marking - Morocco

43. UKCA mark - Great Britain

96. Electrotechnical expert

最小订单数量: 50 NR

条形码

8007352090835

1 NR

8.5x7x3 [cm]

30.8 [g]

8007352090842

50 NR

35.5x24.8x8.7 [cm]

1,731.13 [g]

合法

Vimar保留随时修改所示产品的特性的权利，恕不另行通知。安装必须由符合资质的人员执行，严格遵守所在国家现行的电气材料安装相关规定。有关产品卡信息的使用条件，请参阅使用条件。
