17081
Wiring devices / Traditional wiring devices / IDEA / Mounting frames
Frame 1M +claws grey
1-module mounting frame, grooved front, with claws, for ø 60 mm round flush or 09971 surface mounting boxes, grey
产品状态
3 - Active
图纸
Class group
Domestic switching devices
Domestic switching devices
Class
Holder for modular domestic switching devices
Holder for modular domestic switching devices
Model
Flush-mounted
Flush-mounted
Mounting method
Mounting with claw
Mounting with claw
Mounting method of the module inserts
Back side
Back side
Mounting direction
Horizontal and vertical
Horizontal and vertical
Number of modules horizontal (module system)
1
1
Number of modules vertical (module system)
1
1
With built-in installation box
No
No
With screws
No
No
Suitable for mounting in round junction box 60 mm
Yes
Yes
Flush-mounted installation
Yes
Yes
Suitable for subfloor installation duct box
No
No
Suitable for wall duct
No
No
Suitable for mounting on DIN-rail 35 mm
No
No
Material
Plastic
Plastic
Material quality
Thermoplastic
Thermoplastic
最小订单数量: 50 NR
条形码
8007352045507
1 NR
8.5x7.5x3 [cm]
29.87 [g]
8007352006225
50 NR
35.5x24.8x8.7 [cm]
1,649.47 [g]
