1P 10AX 2-way switch mechanism - 19004.0

Pdf

19004.0
Wiring devices / Traditional wiring devices / ARKÉ / Devices

1P 10AX 2-way switch mechanism
1P 10 AX 250 V~ 2-way switch mechanism, lightable, to complete with 1, 2 or 3-module button. Max 100 W for lamps with built-in power unit(IEC 60669-1:2017)

产品状态
3 - Active

图纸

Class group
Domestic switching devices
Class
Installation switch
Wiring system
Two-way switch
Method of operation
Rocker/button
Assembly arrangement
Modular device for domestic switching devices
Number of modules (module system)
1
Push button switch
Yes
Number of rockers
1
Mounting method
Flush-mounted
Type of fastening
Engage (snap)
With mounting plate
No
Material
Plastic
Material quality
Thermoplastic
Surface protection
Untreated
Surface finishing
Matt
Colour
Blue
RAL-number (similar)
7015
Label space/information surface
Yes
Illumination
Optional
Function lighting
Control and orientation
Suitable for degree of protection (IP)
IP40
Nominal voltage
250 V
Rated current
10,00 A
Feedback-signal contact
No
Connection type
Screwed terminal
Washing machine switch
No

00. CE Marking - EU

10. EAC Eurasian Customs Union

19. NOM - Mexico

29. QCERT - Colombia

36. ISI - India

37. Marking - Morocco

43. UKCA mark - Great Britain

最小订单数量: 20 NR

条形码

Barcode Qty 1 NR
8007352685123
1 NR
4.1x2.8x5.3 [cm]
25.3 [g]
Barcode Qty 20 NR
8007352685130
20 NR
21.4x11.6x6 [cm]
565.1 [g]
Barcode Qty 460 NR
8007352685147
460 NR
57.5x22.5x30 [cm]
14,170 [g]
