1P NO 10A push button mech.screwless - 19008.FX.0

Pdf
Vimar - 19008.FX.0 - 1P NO 10A push button mech.screwless
Vimar - 19008.FX.0 - 1P NO 10A push button mech.screwless
19008.FX.0

Arké / Devices / Basic devices

1P NO 10A push button mech.screwless
1P NO 10 A 250 V~ push button mechanism, screwless terminals, lightable, to complete with 1, 2 or 3-module button

产品状态
3 - Active

Class group
Domestic switching devices
Class
Push button
Assembly arrangement
Modular device for domestic switching devices
Model
Single push button
Method of operation
Push button
Number of rockers
1
Number of modules (module system)
100
Number of poles
1
Nominal voltage
250 V
Rated current
10,00 A
With lighting
Yes
Feedback-signal contact
No
Mounting method
Flush-mounted
Type of fastening
Engage (snap)
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Untreated
Surface finishing
Matt
Colour
Blue
RAL-number (similar)
7015
Transparent
No
Label space/information surface
Yes
Suitable for degree of protection (IP)
IP40
Device width
22,30 mm
Device height
49,00 mm
Device depth
36,30 mm

00. CE Marking - EU

04. NF - France

09. VDE - Germany

10. EAC Eurasian Customs Union

37. Marking - Morocco

43. UKCA mark - Great Britain

96. Electrotechnical expert

99. WEEE Directive

最小订单数量: 20 NR

条形码

Barcode Qty 1 NR
8007352514867
1 NR
5.1x2.8x5.3 [cm]
21.8 [g]
Barcode Qty 20 NR
8007352514874
20 NR
27x11.6x6 [cm]
494.7 [g]
