1P 16AX reversing-switch 2M Metal - 19013.2.M

Pdf
19013.2.M

Arké Metal / Devices / Basic devices

1P 16AX reversing-switch 2M Metal
1P 16 AX 250 V~ reversing switch, lightable, replaceable button, Metal - 2 modules. Max 200 W for self-ballasted lamps (IEC 60669-1:2017)

产品状态
3 - Active

Class group
Domestic switching devices
Class
Installation switch
Wiring system
Intermediate switch
Method of operation
Rocker/button
Assembly arrangement
Modular device for domestic switching devices
Number of modules (module system)
2
Push button switch
Yes
Number of rockers
1
Mounting method
Flush mounted (plaster)
Type of fastening
Engage (snap)
With mounting plate
No
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Lacquered
Surface finishing
Matt
Colour
Aluminium
RAL-number (similar)
9007
Label space/information surface
Yes
Illumination
Optional
Function lighting
Control and orientation
Type of lighting
LED exchangeable
Suitable for degree of protection (IP)
IP40
Nominal voltage
250 v
Rated current
16 A
Feedback-signal contact
No
Connection type
Screwed terminal
Washing machine switch
No
Width of device
44,80 mm
Height of device
49,00 mm
Depth of device
36,85 mm
Built-in depth
25,00 mm

00. CE Marking - EU

04. NF - France

10. EAC Eurasian Customs Union

14. TSE - Turkey

19. NOM - Mexico

31. TISI - Thailand

36. ISI - India

37. Marking - Morocco

最小订单数量: 20 NR

条形码

Barcode Qty 1 NR
8007352598355
1 NR
5.1x4.3x5.3 [cm]
41.6 [g]
Barcode Qty 20 NR
8007352598362
20 NR
26.9x11.6x9 [cm]
910.7 [g]
