2P 20AX 1-way switch WATER/HEATER Metal - 19016.WH.M

Pdf
Vimar - 19016.WH.M - 2P 20AX 1-way switch WATER/HEATER Metal
Vimar - 19016.WH.M - 2P 20AX 1-way switch WATER/HEATER Metal
19016.WH.M

Arké Metal / Devices / Basic devices

2P 20AX 1-way switch WATER/HEATER Metal
2P 20 AX 250 V~ 1-way switch, lightable, WATER/HEATER symbol, Metal. Max 250 W for self-ballasted lamps (IEC 60669-1:2017)

产品状态
3 - Active

Class group
Domestic switching devices
Class
Installation switch
Wiring system
2-pole switch
Method of operation
Rocker/button
Assembly arrangement
Modular device for domestic switching devices
Number of modules (module system)
1
Push button switch
Yes
Number of rockers
1
Mounting method
Flush mounted (plaster)
Type of fastening
Engage (snap)
With mounting plate
No
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Lacquered
Surface finishing
Matt
Colour
Aluminium
RAL-number (similar)
9007
Label space/information surface
Yes
Illumination
Optional
Function lighting
Control and orientation
Type of lighting
LED exchangeable
Suitable for degree of protection (IP)
IP40
Nominal voltage
250 v
Rated current
20 A
Feedback-signal contact
No
Connection type
Screwed terminal
Washing machine switch
Yes
Width of device
22,30 mm
Height of device
49,00 mm
Depth of device
37,10 mm
Built-in depth
26,00 mm

00. CE Marking - EU

00. CE Marking - EU

01. IMQ - Italy

36. ISI - India

37. Marking - Morocco

92. RoHS UAE

99. WEEE Directive

最小订单数量: 50 NR

条形码

Barcode Qty 1 NR
8007352600997
1 NR
4.1x2.8x5.3 [cm]
33.4 [g]
Barcode Qty 50 NR
8007352601000
50 NR
21.4x11.6x14.2 [cm]
1,761.8 [g]
