2P 32A 1-way switch white - 19017.B

Pdf
19017.B

Arké white / Devices / Basic devices

2P 32A 1-way switch white
2P 32 A 250 V~ 1-way switch, lightable, with built-in frame for British standard square boxes, to complete with British standard cover plates, white. Max 200 W for integrated ballast lamps (IEC 60669-1:2017)

产品状态
3 - Active

Class group
Domestic switching devices
Class
Switch
Wiring system
2-pole switch
Method of operation
Rocker/button
Assembly arrangement
Other
Number of modules (module system)
1
Push button switch
Yes
Number of rockers
1
Mounting method
Flush mounted (plaster)
Type of fastening
Engage (snap)
With mounting plate
No
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Lacquered
Surface finishing
Matt
Colour
White
RAL-number (akin)
9016
Label space/information surface
Yes
Illumination
Optional
Function lighting
Control and orientation
Type of lighting
Not included
Suitable for degree of protection (IP)
IP40
Nominal voltage
250 v
Rated current
32 A
Feedback-signal contact
No
Connection type
Screwed terminal
Washing machine switch
Yes
Width of device
84,30 mm
Height of device
82,50 mm
Depth of device
32,20 mm
Built-in depth
22,50 mm
最小订单数量: 10 NR

条形码

Barcode Qty 1 NR
8007352592841
1 NR
8.5x3.9x8.6 [cm]
117.3 [g]
Barcode Qty 10 NR
8007352592858
10 NR
20.7x18.5x9.6 [cm]
1,291 [g]
