2P 32A 1-way switch WATER/HEATER Metal - 19017.WH.M

Pdf

19017.WH.M
Wiring devices / Traditional wiring devices / ARKÉ / Devices

2P 32A 1-way switch WATER/HEATER Metal
2P 32 A 250 V~ 1-way switch, lightable, WATER/HEATER symbol, with built-in frame for British standard square boxes, to complete with British standard cover plates, Metal. Max 200 W for integrated ballast lamps (IEC 60669-1:2017)

产品状态
3 - Active

Class group
Domestic switching devices
Class
Installation switch
Wiring system
2-pole switch
Method of operation
Rocker/button
Assembly arrangement
Other
Number of modules (module system)
1
Push button switch
Yes
Number of rockers
1
Mounting method
Flush-mounted
Type of fastening
Engage (snap)
With mounting plate
No
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Lacquered
Surface finishing
Matt
Colour
Aluminium
RAL-number (similar)
9007
Label space/information surface
Yes
Illumination
Optional
Function lighting
Control and orientation
Type of lighting
LED exchangeable
Suitable for degree of protection (IP)
IP40
Nominal voltage
250 V
Rated current
32,00 A
Feedback-signal contact
No
Connection type
Screwed terminal
Washing machine switch
Yes
Device width
84,30 mm
Device height
82,50 mm
Device depth
32,20 mm
Built-in depth
22,50 mm

00. CE Marking - EU

37. Marking - Morocco

43. UKCA mark - Great Britain

最小订单数量: 10 NR

条形码

Barcode Qty 1 NR
8007352598607
1 NR
8.5x3.9x8.6 [cm]
117.3 [g]
Barcode Qty 10 NR
8007352598614
10 NR
20.7x18.5x9.6 [cm]
1,285 [g]

分享

Codice QR scheda articolo

合法

Vimar保留随时修改所示产品的特性的权利,恕不另行通知。 安装必须由符合资质的人员执行,严格遵守所在国家现行的电气材料安装相关规定。 有关产品卡信息的使用条件,请参阅 使用条件
