Vimar - 19062.AB - 2 interlock.1PNO+NO10A pushes antibact.g

19062.AB
Wiring devices / Traditional wiring devices / ARKÉ / Devices

2 interlock.1PNO+NO10A pushes antibact.g
Two interlocked push buttons, 1P NO + 1P NO 10 A 250 V~, with directional arrows, antibacterial material, grey

产品状态
3 - Active

图纸

PNG DXF

Class group
Domestic switching devices

Class
Push button

Assembly arrangement
Modular device for domestic switching devices

Model
Other

Method of operation
Push button

Number of rockers
1

Number of modules (module system)
100

Number of poles
1

Nominal voltage
250 V

Rated current
10,00 A

With lighting
No

Feedback-signal contact
No

Mounting method
Flush-mounted

Type of fastening
Engage (snap)

Material
Plastic

Material quality
Thermoplastic

Halogen free
Yes

Anti-bacterial treatment
Yes

Surface protection
Other

Surface finishing
Matt

Colour
Grey

RAL-number (similar)
7015

Transparent
No

Label space/information surface
Yes

Suitable for degree of protection (IP)
IP40

Device width
22,30 mm

Device height
49,00 mm

Device depth
38,40 mm

00. CE Marking - EU

10. EAC Eurasian Customs Union

43. UKCA mark - Great Britain

99. WEEE Directive

最小订单数量: 20 NR

条形码

8007352652422

1 NR

4.1x2.8x5.3 [cm]

32.9 [g]

8007352652439

20 NR

21.4x11.6x6 [cm]

739 [g]

8007352653788

460 NR

57.5x22.5x30 [cm]

17,004 [g]

合法

Vimar保留随时修改所示产品的特性的权利，恕不另行通知。安装必须由符合资质的人员执行，严格遵守所在国家现行的电气材料安装相关规定。有关产品卡信息的使用条件，请参阅使用条件。
