2 interlock.1PNO+NO10A pushes antibact.w - 19062.AB.B

Pdf
19062.AB.B

Arké white / Devices / Devices - other functions

2 interlock.1PNO+NO10A pushes antibact.w
Two interlocked push buttons, 1P NO + 1P NO 10 A 250 V~, with directional arrows, antibacterial material, white

产品状态
3 - Active

Class group
Domestic switching devices
Class
Push-switch button
Assembly arrangement
Modular device for domestic switching devices
Model
Other
Method of operation
Push button
Contacts
1 make contact (NO)
Number of poles
1
Feedback-signal contact
No
Number of rockers
1
Number of modules (module syst
1
With lighting
No
Mounting method
Flush mounted (plaster)
Type of fastening
Engage (snap)
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Other
Surface finishing
Matt
Antibacterial treatment
Yes
Colour
White
RAL-number (akin)
9016
Transparent
No
Label space/information surfac
Yes
Suitable for degree of protect
IP40
Nominal voltage
250 v
Rated current
10,00 A
Width of device
22,30 mm
Height of device
49,00 mm
Depth of device
38,40 mm
最小订单数量: 20 NR

条形码

Barcode Qty 1 NR
8007352652446
1 NR
4.1x2.8x5.3 [cm]
32.9 [g]
Barcode Qty 20 NR
8007352652453
20 NR
21.4x11.6x6 [cm]
739 [g]
Barcode Qty 460 NR
8007352653795
460 NR
57.5x22.5x30 [cm]
17,004 [g]
