Axial 1P 10AX 1-way switch 2M Metal - 19100.2.M

Pdf
Vimar - 19100.2.M - Axial 1P 10AX 1-way switch 2M Metal
Vimar - 19100.2.M - Axial 1P 10AX 1-way switch 2M Metal

19100.2.M
Wiring devices / Traditional wiring devices / ARKÉ / Devices

Axial 1P 10AX 1-way switch 2M Metal

产品状态
3 - Active

图纸

PNG DXF
PNG DXF
PNG DXF
Class group
Domestic switching devices
Class
Installation switch
Wiring system
Off switch 1-pole
Method of operation
Rocker/button
Assembly arrangement
Modular device for domestic switching devices
Number of modules (module system)
2
Push button switch
Yes
Number of rockers
1
Mounting method
Flush-mounted
Type of fastening
Engage (snap)
With mounting plate
No
Material
Plastic
Material quality
Thermoplastic
Surface protection
Lacquered
Surface finishing
Matt
Colour
Aluminium
RAL-number (similar)
9007
Label space/information surface
Yes
Illumination
Optional
Function lighting
Control and orientation
Suitable for degree of protection (IP)
IP40
Nominal voltage
250 V
Rated current
10,00 A
Feedback-signal contact
No
Connection type
Screwed terminal
Washing machine switch
No

00. CE Marking - EU

01. IMQ - Italy

10. EAC Eurasian Customs Union

15. CCC - China

28. NSW - Australia

29. QCERT - Colombia

36. ISI - India

37. Marking - Morocco

43. UKCA mark - Great Britain

96. Electrotechnical expert

99. WEEE Directive

最小订单数量: 10 NR

条形码

Barcode Qty 1 NR
8007352685192
1 NR
5x4.7x5.1 [cm]
42.1 [g]
Barcode Qty 10 NR
8007352685208
10 NR
24.8x10.6x6 [cm]
477.9 [g]
