Axial 1P 10AX 1-way switch white - 19100.B

Pdf

Vimar - 19100.B - Axial 1P 10AX 1-way switch white

19100.B
Wiring devices / Traditional wiring devices / ARKÉ / Devices

Axial 1P 10AX 1-way switch white
Axial 1P 10 AX 250 V~ 1-way switch, lightable, replaceable button, white. Max 100 W for lamps with built-in power unit(IEC 60669-1:2017)

产品状态
3 - Active

图纸

PNG DXF

PNG DXF

PNG DXF

Class group
Domestic switching devices

Class
Installation switch

Wiring system
Off switch 1-pole

Method of operation
Rocker/button

Assembly arrangement
Modular device for domestic switching devices

Number of modules (module system)
1

Push button switch
Yes

Number of rockers
1

Mounting method
Flush-mounted

Type of fastening
Engage (snap)

With mounting plate
No

Material
Plastic

Material quality
Thermoplastic

Surface protection
Untreated

Surface finishing
Matt

Colour
White

RAL-number (similar)
9016

Label space/information surface
Yes

Illumination
Optional

Function lighting
Control and orientation

Suitable for degree of protection (IP)
IP40

Nominal voltage
250 V

Rated current
10,00 A

Feedback-signal contact
No

Connection type
Screwed terminal

Washing machine switch
No

00. CE Marking - EU

01. IMQ - Italy

10. EAC Eurasian Customs Union

15. CCC - China

28. NSW - Australia

29. QCERT - Colombia

36. ISI - India

37. Marking - Morocco

43. UKCA mark - Great Britain

96. Electrotechnical expert

99. WEEE Directive

最小订单数量: 20 NR

条形码

8007352684973

1 NR

5.1x2.8x5.3 [cm]

28.6 [g]

8007352684980

20 NR

27x11.6x6 [cm]

637.4 [g]

8007352684997

120 NR

37.5x30x13.5 [cm]

4,184.4 [g]
