Axial 1P 16AX reversing switch white - 19113.B

Pdf
19113.B

Arké white / Devices / Basic devices

Axial 1P 16AX reversing switch white
Axial 1P 16 AX 250 V~ reversing switch, lightable, replaceable button, white. Max 200 W for self-ballasted lamps (IEC 60669-1:2017)

产品状态
3 - Active

您可能也感兴趣

Class group
Domestic switching devices
Class
Installation switch
Wiring system
Intermediate switch
Method of operation
Rocker/button
Assembly arrangement
Other
Number of modules (module system)
1
Push button switch
Yes
Number of rockers
0
Mounting method
Flush mounted (plaster)
Type of fastening
Engage (snap)
With mounting plate
No
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Untreated
Surface finishing
Matt
Colour
White
RAL-number (similar)
9016
Label space/information surface
Yes
Illumination
Optional
Function lighting
Control and orientation
Type of lighting
LED exchangeable
Suitable for degree of protection (IP)
IP40
Nominal voltage
250 v
Rated current
16 A
Feedback-signal contact
No
Connection type
Screwed terminal
Washing machine switch
No
Width of device
22,30 mm
Height of device
49,00 mm
Depth of device
44,70 mm
Built-in depth
34,50 mm
最小订单数量: 20 NR

条形码

Barcode Qty 1 NR
8007352459106
1 NR
5.1x2.8x5.3 [cm]
37.3 [g]
Barcode Qty 20 NR
8007352459113
20 NR
27x11.6x6 [cm]
814.2 [g]
Barcode Qty 120 NR
8007352651418
120 NR
37.5x30x13.5 [cm]
5,244 [g]
