19507.B

Arké white / Mounting frames / Special mounting frames

Frame for RF device white
Frame for surface mounting of EnOcean, Bluetooth, ZigBee devices, to complete with Arké 2-central-module or 2-module cover plates, white

产品状态
3 - Active

您可能也感兴趣

07937 - Screw for frame fixing - 35mm

07939 - Screw for frame fixing - 50 mm

视频

Arké lives in your time

图纸

PNG DXF

Class group
Domestic switching devices

Class
Holder for modular domestic switching devices

Model
Flush mounted (plaster)

Mounting method
Mounting with screw

Mounting method of the module inserts
Front side

Mounting direction
Horizontal and vertical

Number of modules horizontal (module system)
2

Number of modules vertical (module system)
1

With built-in installation box
No

With screws
No

Suitable for mounting in round junction box 60 mm
Yes

Flush-mounted installation
Yes

Suitable for floor box
No

Suitable for wall duct
No

Suitable for mounting on DIN-rail 35 mm
No

Material
Plastic

Material quality
Thermoplastic

29. QCERT - Colombia

37. Marking - Morocco

最小订单数量: 10 NR

条形码

8007352457973

1 NR

11.8x7.3x0.8 [cm]

24 [g]

8007352457980

10 NR

13.9x11.9x7.4 [cm]

287.4 [g]
