16 A IoT connected actuator grey - 19593

Pdf
Immagine 19593
产品图片下载

19593
Wiring devices / View Wireless wiring devices / ARKÉ / Devices

16 A IoT connected actuator grey
View Wireless connected electronic control device with NO 16(3,5)A 100-240 V~ 50/60 Hz relay output, local control with push button or remote control, double technology with Bluetooth® wireless technology 5.0 standard for the realization of View Wireless mesh system and Zigbee 3.0 standard, function for measuringthe instant power and load cut-off threshold, RGB LED visible in darkness with brightness control, 100-240 V 50/60 Hz power supply, grey

  • Configuration from View Wireless App for Bluetooth technology system and Amazon App for Zigbee technology
  • Compatible with Alexa, Google Home and IFTTT, using the dedicated gateway or Zigbee hub
  • Compatible with SmartThings hub

产品状态
3 - Active

您可能也感兴趣

03925
03925 - Bluetooth Low Energy RF device
19597
19597 - IoT connected gateway 2M grey
19203
19203 - 2P+E 16A P17/11 outlet grey
Class group
Installation bus systems
Class
Switch actuator for bus system
Bus system KNX
No
Bus system KNX-RF (Radio Frequency)
No
Bus system radio frequency
Yes
Bus system LON
No
Bus system Powernet
No
Other bus systems
Other
Radio frequency bidirectional
Yes
Mounting method
Flush-mounted
Width in number of modular spacings
1
Local operation/hand operation
Yes
With LED indication
Yes
Max. number of switching contacts
1
Rated current
16 A
Rated operating voltage
100,00 - 240,00 V
Different phases connectable
No
With bus connection
Yes
Bus module detachable
No
Modular expandability
No

00. CE Marking - EU

01. IMQ - Italy

19. NOM - Mexico

29. QCERT - Colombia

37. Marking - Morocco

40. Bluetooth technology

42. Zigbee certified

46. UK PSTI compliance

47. Works with SmartThings

92. RoHS UAE

96. Electrotechnical expert

99. WEEE Directive

最小订单数量: 1 NR

条形码

Barcode Qty 1 NR
8007352628427
1 NR
5.2x3.5x5.3 [cm]
45 [g]
Barcode Qty 60 NR
8007352628434
60 NR
27x23x12.5 [cm]
2,890 [g]
问题： How many devices can I install in a Wireless system?
回答： The system allows the configuration of a maximum of 64 devices for each gateway code 14597-16497-19597-20597
问题： Which App is dedicated to system configuration?
回答： The system can be configured using the View Wireless App.
问题： How do you reset the devices?
回答： Resetting is done by pressing the configuration push button for a prolonged amount of time, which must be done within 5 min of commissioning (powering) the product.
问题： Which function envisages the actuator device art.14593-19593-20593-16593, configured in energy monitoring mode?
回答： The product allows the display of the energy consumed and the disconnection upon exceeding a given threshold which can be set by the user.
问题： How many Energy meters art.02963 can I install in a Wireless system?
回答： Each connected system allows a maximum of 2 meters art.02963.
问题： Can the connected 2-way switch art.14592-19492-19592-20592 be used as a 1-way switch for a controlled socket outlet
回答： No, as a minimum load of 2W is necessary for correct operation. To manage a controlled socket outlet, you can use art. 14593-16493-19593-20593 or art. 03981
