Frame 1M BS - 19606

Pdf
Vimar - 19606 - Frame 1M BS
Vimar - 19606 - Frame 1M BS
19606

Arké / Mounting frames / For square boxes

Frame 1M BS
1-module mounting frame, with screws, for British standard mounting boxes, grey

  • The transparency helps the installation and the wiring of devices
  • The honeycomb structure gives structural strength
  • The slots in the corners enable fixing to the panel
  • Thanks to the central slots, the support can be fixed onto the wall level

产品状态
3 - Active

Class group
Domestic switching devices
Class
Holder for modular domestic switching devices
Model
Flush mounted (plaster)
Mounting method
Mounting with screw
Mounting method of the module inserts
Front side
Mounting direction
Horizontal and vertical
Number of modules horizontal (module system)
1
Number of modules vertical (module system)
1
With built-in installation box
No
With screws
Yes
Suitable for mounting in round junction box 60 mm
No
Flush-mounted installation
Yes
Suitable for floor box
No
Suitable for wall duct
No
Suitable for mounting on DIN-rail 35 mm
No
Material
Plastic
Material quality
Thermoplastic

00. CE Marking - EU

01. IMQ - Italy

08. ASTA - UK

29. QCERT - Colombia

43. UKCA mark - Great Britain

96. Electrotechnical expert

最小订单数量: 40 NR

条形码

Barcode Qty 1 NR
8007352605312
1 NR
8.2x8.2x1.5 [cm]
40 [g]
Barcode Qty 40 NR
8007352588820
40 NR
28.4x18.4x13.7 [cm]
1,729.8 [g]
