19614
Wiring devices / Traditional wiring devices / ARKÉ / Mounting frames
Frame 4M +screws
4-module mounting frame, with screws, for 4-module mounting boxes
产品状态
3 - Active
您可能也感兴趣
Class group
Domestic switching devices
Domestic switching devices
Class
Holder for modular domestic switching devices
Holder for modular domestic switching devices
Model
Flush-mounted
Flush-mounted
Type of fastening
Other
Other
Mounting method of the module inserts
Front side
Front side
Mounting direction
Horizontal and vertical
Horizontal and vertical
Number of modules horizontal (module system)
4
4
Number of modules vertical (module system)
1
1
With built-in installation box
No
No
With screws
Yes
Yes
Suitable for mounting in round junction box 60 mm
No
No
Flush-mounted installation
Yes
Yes
Suitable for subfloor installation duct box
No
No
Suitable for wall duct
No
No
Suitable for mounting on DIN-rail 35 mm
No
No
Material
Plastic
Plastic
Material quality
Thermoplastic
Thermoplastic
Surface protection
Untreated
Untreated
最小订单数量: 40 NR
条形码
8007352427587
1 NR
14x7.3x2.1 [cm]
22.6 [g]
8007352427594
40 NR
28.4x24.4x16.4 [cm]
1,123 [g]
8007352470026
160 NR
59.5x38.5x26.5 [cm]
5,204 [g]
8007352482630
1,920 NR
120x80x93.5 [cm]
60,576 [g]
