Classic plate 3M technopolymer ivory - 19653.73

Pdf

Vimar - 19653.73 - Classic plate 3M technopolymer ivory

19653.73
Wiring devices / Traditional wiring devices / ARKÉ / Cover plates

Classic plate 3M technopolymer ivory
3-module Classic cover plate, technopolymer, ivory

产品状态
3 - Active

您可能也感兴趣

19613 - Frame 3M +screws

视频

Arké lives in your time

图纸

PNG DXF

PNG DXF

PNG DXF

Class group
Domestic switching devices

Class
Cover frame for domestic switching devices

Number of units
3

Mounting direction
Horizontal and vertical

Number of units horizontal
3

Number of units vertical
1

Number of modules horizontal (module system)
3

Number of modules vertical (module system)
1

With mounting grid
Yes

Suitable for subfloor installation duct box
Yes

Suitable for wall duct
Yes

Suitable for built-in installation
Yes

Label space/information surface
Yes

Material
Plastic

Material quality
Thermoplastic

Halogen free
Yes

Surface protection
Untreated

Surface finishing
Matt

Colour
White

RAL-number (similar)
9002

Transparent
No

With hinged lid
No

Degree of protection (IP)
IP00

Type of fastening
Clamp mounting

Width
122,00 mm

Height
90,00 mm

Depth
8,60 mm

Built-in width
122,00 mm

Built-in height
90,00 mm

Diameter bore hole (opening)
0 mm

00. CE Marking - EU

01. IMQ - Italy

29. QCERT - Colombia

43. UKCA mark - Great Britain

50. Product Environm. Profile

最小订单数量: 10 NR

条形码

8007352439368

1 NR

12.2x9x0.9 [cm]

20 [g]

8007352439375

10 NR

14.1x9.8x9.9 [cm]

249.6 [g]

8007352640535

160 NR

39x29.5x22 [cm]

4,810 [g]
