20000.FX.B
Wiring devices / Traditional wiring devices / EIKON / Devices
1P 10AX 1-way switch screwless white
1P 10 AX 250 V~ 1-way switch, screwless terminals, screwless terminals, lighTable, replaceable button, white. Max 100 W for self-ballasted lamps (IEC 60669-1:2017)
产品状态
3 - Active
图纸
Class group
Domestic switching devices
Domestic switching devices
Class
Installation switch
Installation switch
Wiring system
Off switch 1-pole
Off switch 1-pole
Method of operation
Rocker/button
Rocker/button
Assembly arrangement
Modular device for domestic switching devices
Modular device for domestic switching devices
Number of modules (module system)
1
1
Push button switch
Yes
Yes
Number of rockers
1
1
Mounting method
Flush-mounted
Flush-mounted
Type of fastening
Engage (snap)
Engage (snap)
With mounting plate
No
No
Material
Plastic
Plastic
Material quality
Thermoplastic
Thermoplastic
Halogen free
Yes
Yes
Surface protection
Untreated
Untreated
Surface finishing
Matt
Matt
Colour
White
White
RAL-number (similar)
9016
9016
Label space/information surface
Yes
Yes
Lighting
Optional
Optional
Function lighting
Control and orientation
Control and orientation
Type of lighting
LED exchangeable
LED exchangeable
Suitable for degree of protection (IP)
IP40
IP40
Nominal voltage
250 V
250 V
Rated current
10,00 A
10,00 A
Switching current for fluorescent lamps
10
10
Monitoring contact
No
No
Connection type
Push-in clamp
Push-in clamp
Washing machine switch
No
No
Device width
22,30 mm
22,30 mm
Device height
49,00 mm
49,00 mm
Device depth
38,30 mm
38,30 mm
Built-in depth
26,90 mm
26,90 mm
最小订单数量: 1 NR
条形码
8007352630161
1 NR
5.1x2.8x5.3 [cm]
25.7 [g]
8007352630178
50 NR
27x15x12 [cm]
1,373 [g]
